Trimscape Traditional Plumbing Sink Trim Kit with P-Trap and Drain

Trimscape Traditional Plumbing Sink Trim Kit with P-Trap and Drain

This traditional style vessel sink kit consists of all the necessary parts to set up a sound waste water drainage system. The parts included are single handle 1/2" IPS angle stops, 30" bullnose lavatory supply lines, 1/2" IPS bell flanges, a 1-1/4" P-trap, mounting ring and an 22-gauge push-button drain without overflow hole. Constructed of high quality material and a tarnish-resistant finish, designed for long-lasting performance. Available in a variety of stunning finishes ready to match any home decor.

Features:

• Solid brass construction
• Supply and p-trap plumbing trim kit for bathroom sinks
• Kit contains: 2 angle stops, 2 wall flanges, 2 supply lines, 1 p-trap, 1 p-trap wall flange, 1 drain, 1 mounting ring
• Angle stops designed to fit 1/2” NPT male (exterior threads) stub-out
• Angle stop inlet is 1/2” NPT female (interior threads)
• Angle stop outlet is 3/8” O.D. compression (compression slip fit)
• Angle stops include traditional lever handle
• Includes (2) 2-3/8" bell flanges to cover any unsightly holes
• Two pieces 3/8" x 30" bull nose rigid supply lines
• One traditional style p-trap with flange
• P-trap is 1-1/4” diameter for bathroom sink drains
• P-trap measures 12” from drain inlet center to wall-end
• One "no overflow" drain and mounting ring kit for vessel sink
• 22 gauge 1-1/4" O.D. push-up pop-up drain, no overflow

Finish Disclaimer:

Designer Hardware offers several special finishes that fall into two main groups: antiqued/distressed and living. Our antiqued/intentionally distressed finishes include Antique Brass, Antique Copper, Naples Bronze, and Black Stainless. Our living finish is Oil Rubbed Bronze. Antiqued/distressed finishes have had a darkener applied to create the appearance of patina and age. Due to the nature of plating and distressing processes, each production lot of these finishes varies slightly in brightness and tone. Some degree of inconsistency between items in antiqued or distressed finishes should be expected. We cannot guarantee an exact match between items in these finishes. The differences in tone and brightness are a variation rather than a flaw or defect. Living Finishes change over time. Our Oil Rubbed Bronze will patina over time such as taking on highlights in high-touch areas. We consider this dynamic nature a feature that gives each faucet a unique character over its lifetime of use and does not constitute a defect or flaw. Like our antiqued/distressed finishes, some degree of inconsistency between living finish items should be expected. We cannot guarantee an exact match between items in Oil Rubbed Bronze.

	Specification Sheet
	Parts Diagram
	Installation Guide
